Green overd'r Light & Sounder Custom text Stainless steel
£88.41
Ex Vat
Lead time for this item is 3-5 working days
Product code
S1778SGTC
Green overdoor Light & Sounder Custom text Stainless steel
Stainless Steel flush fitting overdoor light and sounder with 16mm Green Jumbo LED. There are separate terminals provided for the LED. The LED and sounder current limit resistor is provided for 12 vdc operation. Supplied lasered with your own choice of text. Text to be specified when ordering - 45 characters maximum.
-
Specification
- Led Current - 50mA @12vdc
- Switch Contacts - N/A
- Sounder Current - 40mA @ 12vdc
- Visual Indication - 1 x Red Jumbo LED
- Integral Sounder Level - 90dB@10cm
- Tamper - N/A
- Material - 316 Stainless Steel
- Permanently laser marked
- Ideal for hygienic environments
- Dimensions - 86mm x 86mm x 2mm - Facia
- 38mm galvanised back box supplied
- Surface mounted using part no. S0610 listed below
- Weight - 0.26kg
- IP Rating - IP65 front side contact area
- Approvals - CE and RoHs compliant
Weather gasket Code: WG1 is available for the rear of the plate if required. Anti tamper screws available, see related products below
Country of Origin | UK |
---|---|
Condition | New |
SKU | S1778SGTC |
Associated Product Codes | S1778SGTC |
Warranty | 3 Years |
- | Installation Instructions for S1778SGTC |
- | Product Information Sheet for S1778SGTC |
