Aidalarm Overdoor light and Sounder

Overdoor light and Sounder with 8 high brightness yellow LEDs. The LEDs and sounder are current limited for 12vdc operation. There are separate inputs for sounder and LEDs. The single gang low profile white ABS enclosure is supplied with a surface mounting back box. The unit can also be flush fitted in a standard single gang back box.

Specification

• Led Current - 25mA@12vdc
• Sounder Current - 25mA@12vdc
• Switch Contacts - N/A
• Visual Indication -8 x high brightness yellow LEDs
• Integral Sounder Level - 70db@10cm
• Tamper - N/A
• Material - White ABS
• Weight - 0.13kg
• 87 x 87 x 36mm (Surface mount)
• IP Rating - IP44 to maintain the IP rating a suitable sealant or gasket for the rear of the plate is required
• Back box supplied for surface mount
• Approvals - CE and RoHs compliant
• Can be Semi Flushed onto standard flush back box (Not supplied)
• Mark resistant decal

Anti tamper screws available, see related products below
